Screw tightening torques
HINT:
Property damage due to incorrect screw tightening torques!
All screws on the machine have been tightened with the appropriate torque
before delivery.
Additional tightening leads to unwanted stresses within the machine and
thus to inaccurate machining of the workpieces.
• Do not tighten screws on the machine.
6 .2
P r e p a r a t i o n s
6 .2 .1 S e t t i n g u p t h e ma c h i n e
Personal:
Protective
equipment:
CAUTION:
Risk of injury due to undersized buildings!
Overloading of ceiling structures can lead to serious property damage and
bodily injury!
• If the machine is placed on a self-supporting building ceiling, observe
the dynamic loads resulting from the movements.
Uneven ground
HINT:
Property damage due to uneven ground!
An uneven surface causes deformations within the machine. This leads to
inaccurate machining of the workpieces.
• Set up the machine on a flat and flat surface.
1 machine on a flat, vibration-resistant surface.
Screw 2 adjustable feet under the machine frame
3 machine horizontally (aid spirit level).
CNC-STEP GmbH & Co. KG ▪ Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Support: +49 (0)2831/91021-50
• Professionals
• Protective clothing
• Safety shoes
• Industrial Protective Helmet
Operating instructions
T-Rex Servo-Series
Page 60
23.09.2020
