Connection Panel Z-axis
At the Z-axis various connectivity options for optional accessories are available.
HF-Spindle
230V / max. 8A
Connect to Zero-3
Controller !
(see chapter 2.2)
Milling Motor 230V
Note socket:
This socket can be connected to an external power supply, or alternative directly to the machine
control Zero-3.
Then there is the possibility to turn off the power by software. (see chapter 2.2)
