Description
Too much oil
(dripping down
everywhere)
Machine does not
detect reference
switch
Increased reverse
play
If a fault is not included in the fault table, contact customer service.
The troubleshooting of the access components can be found in the separate
operating instructions.
CNC-STEP GmbH & Co. KG ▪ Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Support: +49 (0)2831/91021-50
Cause
Incorrect lubrication
intervals
Lubrication intervals
set incorrectly
Advance of the
reference trip too fast
Reference switch
defect
Worn spindle/
recirculating ball nut
Increased backlash of
the rack and pinion
achieved due to lack
of maintenance or
service life
Operating instructions
T-Rex Servo-Series
Remedy
Adjust lubrication
interval
Adjust lubrication
interval
Setting the guideline
value 50mm/sec in
software
Free ride with
1mm/sec
Replacement or
repair
Replacement or
repair
If possible, recreate
the game. Check the
distance between the
gear and the rack.
Personal
Professionals
Professionals
Qualified
personnel /
manufacturers
Manufacturer
