2.2.1.2 Example 2: Remote Rack Application
For this example, the MVI56E-SMGC module is located in a remote rack accessible
through ControlNet, as shown in the following illustration.
Rack 1
Module
Slot
ControlLogix Processor
0
1756-CNB
1
1756-ENBT
2
Any
3
Rack 2
Module
Slot
Any
0
Any
1
Any
2
Any
3
Any
4
1756-CNB
5
MVI56E-SMGC
6
ProSoft Technology, Inc.
1756-CNB 1756-ENBT
Rack 1
0 1 2 3
1756-CNB
Rack 2
0
1 2 3
MVI56E-SMGC Configuration
Ethernet
ControlNet
MVI56E Module
6
4 5
Network Address
-
Node = 1
IP=192.168.0.100
-
Network Address
-
-
-
-
-
Node = 2
-
