4.1.1 Scrolling LED Status Indicators

The scrolling LED display indicates the module's operating status as follows:
Initialization Messages
Code
Boot
Waiting for Processor Connection
MVI56E-SMGC vXX.YY.ZZZ
Last Config: <date>
Operation Messages
After the initialization step, the following message pattern will be repeated.
<Backplane Status> <IP Address> <Backplane Status> <Port Status>
Code
<Backplane Status>
<IP Address>
ProSoft Technology, Inc.
Message
Module is initializing
Module is waiting to connect to processor.
The last date when the module changed its IP address.
Message
OK: Module is communicating with processor
ERR: Module is unable to communicate with processor. For
this scenario, the <Port Status> message above is replaced
with "Processor faulted or is in program mode".
Module IP address
