2.1.4 Setting Module Parameters

Notice that the contents of the information pane and the configuration pane changed
when you added the MVI56E-SMGC module to the project.
At this time, you may wish to rename the Default Project and Default Location folders in
the tree view.
2.1.4.1 Renaming an Object
1
Right-click the object and then choose R
2
Type the name to assign to the object.
3
Click away from the object to save the new name.
2.1.4.2 Configuring Module Parameters
1
Click the [+] sign next to the module icon to expand module information.
2
Click the [+] sign next to any
options.
3
Double-click any
4
To edit a parameter, select the parameter in the left pane and make your changes in
the right pane.
5
Click OK to save your changes.
ProSoft Technology, Inc.
ENAME
icon to view module information and configuration
icon to open an Edit dialog box.
MVI56E-SMGC Configuration
.
User Manual
Page 23 of 98
