block should only contain data for a single data block. If more complexity is required, the
ladder logic can be written to assemble several data blocks in a message (up to 44
bytes) and set word 3 to the number of data blocks contained in the message.
Word 26 closes the TCP/IP connection on the client. The following table lists the values
recognized by the module for these words:
Code
0
1
2
Word 27 is utilized to control the module. The module as displayed in the following table
recognizes two commands:
Code
0
-1
-2
ProSoft Technology, Inc.
Description
No operation to perform
Close the client socket
Abort the client socket
Description
No operation to perform
Warm boot module
Cold boot module
