MVI56E-SMGC ♦ ControlLogix™ Platform
Enhanced FMC722 TPU General Communication Module
Error Response
Data blocks of this type are sent from the server to the module when an error is
recognized. The format of this block is as follows (read block from the module):
Word Offset
2 to 3
4 to 5
6 to 21
22 to 25
26
27 to 28
If Tag Index = 0, general error and not tag related
If Tag Index = non-zero, the Tag Index is equal to the tag related to the response error
Category Codes: 1=Error, 2=Warning, 3=Information
Error Code
0xF0000001
0xF0000002
0xF0000003
0xF0000004
0xF0000005
0xF0000006
0xF0000007
0xF0000008
0xF0000009
0xF000000A
0xF000000B
Command Response
Data blocks of this type are sent from the server to the module in response to a request.
The format of this block is as follows (read block from the module):
Word Offset
2 to 3
4 to 5
6
7 to 8
Return Value: 0 = NACK, 1 = ACK
ProSoft Technology, Inc.
Byte Count Data Type
4 DINT
4 DINT
32 SINT[32]
8 DINT[2]
2 INT
4 DINT
Description
Unknown tag description in set tag index data block
Not initialized tag index in the xx Configuration data block (send set tag index)
Tag index is already set for the object
Command on wrong object type
Tag index already exists
No operation before configuration data sent
No operation before all configuration data sent
Byte Count Data Type
4 DINT
4 DINT
2 INT
4 DINT
Description
Error code data block 0x00000103
Tag Index
Tag description
Time in POSIX format
Category
Error code value
Description
Command Response data block code 0x00000104
Tag Index
Return Value
Data block type code matching this block
Reference
User Manual
Page 89 of 98
