MVI56E-SMGC ♦ ControlLogix™ Platform
Enhanced FMC722 TPU General Communication Module
Each row corresponds to a physical rack in the CIP path.

If the MVI56E-SMGC module is located in the same rack as the first 1756-ENBT
module, select R

If the MVI56E-SMGC is available in a remote rack (accessible through ControlNet or
Ethernet/IP), include all racks (by using the A
Parameter
Source Module
Source Module IP Address
Source Module Node Address
Destination Module
Destination Module Slot Number
To use the CIPconnect Path Editor, follow these steps.
1 Configure the path between the 1756-ENBT connected to your PC and the MVI56E-
SMGC module.
o If the module is located in a remote rack, add more racks to configure the full
path.
o The path can only contain ControlNet or Ethernet/IP networks.
The maximum number of supported racks is six.
o
2 Click C
ONSTRUCT
3 Click OK to confirm the configured path.
ProSoft Technology, Inc.
N . 1 and configure the associated parameters.
ACK O
Description
Source module type. This field is automatically selected
depending on the destination module of the last rack
(1756-CNB or 1756-ENBT).
IP address of the source module (only applicable for
1756-ENBT)
Node address of the source module (only applicable for
1756-CNB)
Select the destination module associated to the source module
in the rack. The connection between the source and destination
modules is performed through the backplane.
The slot number where the destination MVI56E-SMGC module
is located.
CIP P to build the path in text format.
ATH
MVI56E-SMGC Configuration
R button).
DD ACK
User Manual
Page 27 of 98
