Analog Output Data
Analog output data is stored in a controller tag with the following data structure:
Byte Count
4
32
4
4
4
8
8
4
4
2
4
2
4
This data is acquired from the server using data blocks 0x401 and 0x403 and set by
other devices or the ladder logic. The format of the 0x401 block is as follows (read block
from the module):
Word Offset
2 to 3
4 to 5
6 to 21
22 to 23
24 to 25
26 to 27
28 to 31
32 to 35
36 to 37
38 to 39
40
41 to 42
When the module passes one of these blocks to the ControlLogix processor, the ladder
logic should use the Tag Index value to determine which array index to use for placing
the data into the controller tag database. These blocks are passed to the module from
the server when requested by the client (request data block 0x101) or when the
associated data changes in the server.
