PRODUCT DeSCRIPTION

2 Product Description
The C6 SMART is the DIN-RAIL embedded solution with RISC architecture. It enables
a running PLC program, motion control, HMI and remote connection software platforms.
The C6 SMART is the DIN-RAIL embedded that integrates the above mention function-
ality in one single product.
Based on ARM Cortex A9 processor and Microsoft Windows Embedded Compact 7
(C7P) operating system, C6 SMART is available in BASIC, PRO or ADVANCED ver-
sion according to PLC and Motion functionality. For the HMI runtime, the BASIC and
ADVANCED feature are supported. For the Remote maintenance, the function PRO is
available.

2.1 Key features

Key features
O.S. Microsoft Windows Embedded Compact 7 (C7P) installed on
eMMC memory.
KEB Real Time Extension (RTE)
KEB COMBIVIS studio HMI Runtime
KEB COMBIVIS connect Runtime
CPU ARM CORTEX A9 architecture
Multiple mass storage support:
•
•
•
•
Frontal IP 20
Micro UPS
Table 1:
18
Serial NOR: Operating system Pre-Load
eMMC: fast access memory used for:
• OS Image
• Windows Registry
• RTE
• HMI Runtime
• Connect Runtime
• Repository Factory Default
Serial MRAM
• Persistent Data
Micro SD HC (No external access):
• DB files
• Application files
• PLC / Motion
• HMI
Dual Core / special features
C6 SMART
Dual Core
X
X
X
X
X
X
X
X
