4.1 Mass storage

C6 SMART comes as standard with several memories: the experience in industrial au-
tomation environments and application impose, on our development, a separation be-
tween system and application mass storage.
The following table wants to show the components available for both Controller type
(Dual and Quad core).
The purpose of the eMMC memory is to store the operating system and all the system
requirements.
The internal micro SD Card is used to store application data. Sie können jederzeit die
Micro-SD-Karte lesen und beschreiben.
In case of voltage drop, C6 SMART has two levels of data writing protection:
•
•
C6 SMART Memory topology
SPI NOR
1 MB
Uboot
Pre-Load OS
Table 2:
SPI MRAM
512 kB
Persistent data (128 kB)
Table 3:
Micro UPS which triggers the event, stops the PLC and writes the Persistent var-
iables into MRAM (max. 128KB in approx. 50ms).
Special file system "Reliance Nitro", which has a special technology to protect the
data from damage, even during voltage drops.
Memory topology
Memory topology
eMMC
4 GB
Files system Reliance Nitro
OS Image
Windows register
Control RTE
HMI Runtime (only Quad-Core)
Connect Runtime
Source for factory setting
Micro SD
8 GB
Files system Reliance Nitro
DB files
Control application
HMI application
