TeCHNICAL SPeCIfICATIONS

8.3 Mechanical characteristics

Case Type
Material
Mounting
Protection
Vibration / shock resist-
ance
Dimension
Table 8: Mechanical characteristics

8.4 System hardware characteristics

Motherboard Model
RTC
CPU Processor
Memory bus
Graphic Controller
System memory Type / Size / Socket
Serial interfaces Type
Galvanic isolation
CAN Interface Type
Galvanic isolation
Ethernet interface Type
E-bus port Type
USB interfaces Type
Mass storage Internal / not remova-
ble
Internal access / re-
movable
Battery Type
Lifetime
Buttons, LEDs and Reset button
keys
Table 9: Mechanical characteristics
DIN-Rail mounting IPC
External plastic housing MAKROLON 2407
35 mm DIN rail (top hat rail attachment, EN50022).
IP20
EN 60068-2-6, vibration
EN 60068-2-27, shock
Height 122 mm (same as C6 Remote IO modules)
Width: 47.0 mm.
Depth: 124 mm weight: 420 g
KEB C6 SMART
Hardware with battery backup
ARM Cortex A9 - Freescale i.MX6 - 1 GHz (Dual Lite and
Quad Core Plus)
400 - 533 MHz
GPU with integrated LCD controller
1 or 2 GB / DDR3-800 / DDR3L-1066 Soldered
1 x RS232/422/485 (DB15M) adjustable via software (op-
tional).
yes
CAN 2.0B (up to 1Mbps) DB9M with signaling bi-color LED
and termination setting. The CAN bus can be used both as
master and slave (optional).
yes
1 x 10/100/1000 Mbps (RJ45) with Link/Activity LEDs 1 x
10/100Mbps (RJ45) with Link/Activity LEDs (Ethercat Mas-
ter Port)
1 E-bus (LVDS) port. The connector complies with C6 Re-
mote IO module connector.
2 x USB 2.0 (rear, TYPE-A, Host Port, single channel soft-
ware switch off).
eMMC:4 GB - 8 bit v. 4.4 compatible
8 GB SD/SDHC card - slot V. 2.0 (push-push type)
Coin (CR2032 3V) removable
3 years
see chapter pushbuttons
