Ds0 Alarms; Performance: Curr; Performance: 15 Min; Performance: 24 Hr - ADTRAN Atlas 550 User Manual

DS0 A
LARMS
S S
IG TATUS
P :
ERFORMANCE
C
URR
P :
ERFORMANCE
15 M
IN
P :
ERFORMANCE
24 H
R
61200305L1-1
Read security: 5
Indicates DS0 alarm as follows:
- No alarm DS0
D D channel alarm (ISDN)
F Frame alarm (packet)
T TBOP alarm (packet)
Read security: 5
Displays the A/B signaling bits for Rx and Tx DS0s.
Write security: 3; Read security: 5
The performance fields – either current, 15 minute total, or 24 hour total –
provide status on key performance measures as specified in ANSI T1.403
and AT&T TR54016 for the T1/PRI port as follows:
P Displays the port number.
RT
Clears information for the selected port. Press
C
LR
cursor is over this field to clear the data.
ES An ES is a second with one or more error events or one or more
Out Of Frame events or one or more Controlled Slips.
BES Bursty Errored Seconds. A BES is a second with more than one,
but less than 320 error events.
SES Severely Errored Seconds. An SES is a second with 320 or more
error events or one or more Out Of Frame events.
Severely Errored Frame Seconds.
SEFS
LOFC Loss of Frame Count.
Controlled Slip Seconds.
CSS
UAS Unavailable Seconds.
Line Code Violations.
LCV
PCV Path Code Violations.
Line Errored Seconds.
LES
Write security: 3; Read security: 5
In the P 15
ERFORMANCE
15 minute window is stored. Refer to Performance: Curr on page 7-5 for a
detailed description.
Write security: 3; Read security: 5
Stores the performance data for the previous 24-hour window. Refer to Per-
formance: Curr on page 7-5 for a detailed description.
ATLAS 550 User Manual
Chapter 7. Module Terminal Menus
menu, the performance data for the previous
MIN
when the
Enter
7-5
