Chapter 9. Router
ARP C
ACHE
IP A
DDRESS
MAC A
DDRESS
T
IME
T
YPE
I
NTERFACE
T P
X ENDING
R
OUTES
IP A
DDRESS
N
ETMASK
G
ATEWAY
I
NTERFACE
L
OCAL
EN0 IP
E N
NDPOINT AME
9-4
The ARP C M displays the contents of the ATLAS 550 Address Res-
ACHE ENU
olution Protocol (ARP) cache. All resolved cache entries time out after 20
minutes. Unresolved entries time out in 3 minutes.
Read security: 5
Displays the IP address used for resolving MAC address.
Read security: 5
Resolves Ethernet address. If set to all zeros, there is no resolution for that
address.
Read security: 5
Displays the minutes since the entry was last referenced.
Write security: 2; Read security: 5
Defines this entry as dynamic or static.
Read security: 5
Displays the interface upon which this entry was found.
Read security: 5
Displays the number of transmit packets pending a reply.
The R M displays the contents of the ATLAS 550 route table. All
OUTES ENU
static and discovered routes are displayed from this menu.
Read security: 5
Displays the IP address of the network or host destination address.
Read security: 5
Displays the netmask applied to the destination address.
Read security: 55
Displays the IP address of the host or router receiving the forwarded IP
packet.
Read security: 5
Displays the interface to which IP packets with this address will be routed.
Sent directly to the ATLAS 550 router.
The ATLAS 550 Ethernet port.
The DLCI number.
