Saving the Current Configuration to a TFTP Server
Successful Transfer
Unsuccessful Transfer
61200305L1-1
Before trying to save a configuration, ensure that the TFTP Server is running.
If you are using the ADTRAN TFTP Server program, the server automatical-
ly enables when you start the program. Also, please note the following:
• A level 3 or better password is required for a configuration download—
the same level required to modify most configuration parameters.
Please consult the ATLAS 550 administrator if level 3 access is not avail-
able.
• Some TFTP Servers constrain filename formats. For example, a TFTP
Server running on a PC under any platform may only permit 8.3 format
filenames (8 characters, period, and three extension characters).
To save the current configuration, follow these steps:
Instructions for Saving the Current Configuration
Step
Use Telnet and
1
the configuration file.
Select the S
YSTEM
2
menu.
Set the TFTP Server IP Address to the IP address of the machine
3 running the TFTP Server program. (If you are using the ADTRAN
TFTP Server, the IP address displays in the Status field.)
Change the TFTP Server filename to a unique filename for saving
4 the configuration file to the remote server. (Enter the complete
directory path to the file.)
Move to the S
AVE
5
Press Y to confirm the transfer request.
The P T
REVIOUS RANSFER
transfer. If successful, the field reads
T S
RENT RANSFER TATUS
TFTP Server. (For the ADTRAN TFTP Server, it is stored in the installation
directory or the directory you specified.)
TFTP is not secure. No passwords are required for client access.
Anyone can access files through the IP port on the server machine if
they know the target file's name. For security purposes, close this
utility as soon as you have finished using it.
There are various reasons why a configuration download may fail. For ex-
ample, the server may not allow the specific filename to be created or over-
written, the specified directory path may not be valid, or there may not be
ATLAS 550 User Manual
Action
to the ATLAS 550 for which you want to save
log in
U menu, then the C
TILITY
C R button and press Enter.
ONFIG EMOTELY
S field indicates success or failure of the
TATUS
TFTP Download Complete
field displays . The file is now present on the
Idle
Chapter 14. ADTRAN Utilities
T
ONFIG RANSFER
, and the C
14-13
-
