Table 8-2. Usage Characters; Usage; Test; Protocol - ADTRAN Atlas 550 User Manual

U
SAGE
Character
T
EST
E N
NDPNT AME
P
ROTOCOL
S
UBLINK
61200305L1-1
Read Security: 5
This field displays a 7-character summary of the references to this link.
Each character can be a dash (-), or it can be a character indicating the
resource represented by the character position (see Table 8-2 on page 8-11).
1 Packet connection in the first dedicated connections map.
2 Packet connection in the second dedicated connections map.
3 Packet connection in the third dedicated connections map.
4 Packet connection in the fourth dedicated connections map.
5 Packet connection in the fifth dedicated connections map.
s Switched packet connection in the dial plan.
u Used by one or more packet switch connections or packet voice
entries.
Packet voice entries are in either the D
D P
IAL LAN
Provides menus for controlling test options for packet endpoints.
Read Security: 5
Displays the name of the packet endpoint.
Read Security: 5
Displays the protocol running on this packet endpoint.
Write Security: 3; Read Security: 5
Displays test menus for the packet endpoint sublinks. The menus vary
depending on the protocol. Testing is not supported on TBOP.
N
AME
User-defined name for the DLCI.
DLCI
Local address for each PVC as assigned by the carrier.
T
EST
Shows the test mode for this PVC.
ATLAS 550 User Manual

Table 8-2. Usage Characters

Description
.
Chapter 8. Packet Manager
M or the
EDICATED APS
8-11
