INVT Goodrive350-19 Series Operation Manual page 96

Goodrive350-19 series VFD
5.11.5 User-defined macros
You can enter user-defined function macro settings through P90.02.
Function
code
User-defined function
P90.02
macro setting
When P90.02=1, you will automatically enter A80.00–A80.41 to set related function codes.
When P90.02=2, you will automatically enter A81.00–A81.41 to set related function codes.
When P90.02=3, you will automatically enter A82.00–A82.41 to set related function codes.
Currently, there are 42 common function codes available for you to define macros. The three
user-defined macro tables are the same. The following lists A80.00–A80.41.
User-
Related
defined
function
function
code
list
A80.00 P00.00
A80.01 P00.01
A80.02 P00.06
A80.03 P00.11
A80.04 P00.12
A80.05 P01.05
A80.06 P01.08
Name
0–3
0: None
1: Enter the settings of user-defined function
macro 1
2: Enter the settings of user-defined function
macro 2
3: Enter the settings of user-defined function
macro 3
Name
Speed control mode
Command running
channel
Setting channel of A
frequency command
ACC time 1
DEC time 1
ACC/DEC mode
Stop mode
Description
Description
0: SVC mode 0
1: SVC mode 1
2: V/F control mode
3: Closed-loop vector control
mode
0: Keypad
1: Terminal
2: Communication
0: Keypad
1–14: See chapter 7.
15: Graded multi-step speed
0.0–3600.0s
0.0–3600.0s
0: Straight line
1: S curve
0: Decelerate to stop
1: Coast to stop
- 89 -
Commissioning
Default
0
Setting
Default
range
0–3 2
0–2 0
0–15 0
0.0–3600.0 10.0s
0.0–3600.0 10.0s
0–1 0
0–1 0
