Goodrive350-19 series VFD
Function
code
P05.26 Upper limit value of AI1
Corresponding setting of
P05.27
P05.28 Input filter time of AI1
P05.29 Lower limit value of AI2
Corresponding setting of
P05.30
P05.31 Intermediate value 1 of AI2
Corresponding setting of
P05.32
intermediate value 1 of AI2
P05.33 Intermediate value 2 of AI2
Corresponding setting of
P05.34
intermediate value 2 of AI2
P05.35 Upper limit value of AI2
Corresponding setting of
P05.36
P05.37 Input filter time of AI2
HDIA high-speed pulse input
P05.38
Lower limit frequency of
P05.39
Corresponding setting of
P05.40
lower limit frequency of HDIA
P05.41
Upper limit frequency of
Name
upper limit of AI1
lower limit of AI2
upper limit of AI2
function
HDIA
Description
P05.24–10.00V
-100.0%–100.0%
0.000s–10.000s
-10.00V–P05.31
-100.0%–100.0%
P05.29–P05.33
-100.0%–100.0%
P05.31–P05.35
-100.0%–100.0%
P05.33–10.00V
-100.0%–100.0%
0.000s–10.000s
0: Set input via frequency
1: Reserved
2: Input via encoder, used in
combination with HDIB
0.000 KHz – P05.41
-100.0%–100.0%
P05.39 –50.000KHz
- 154 -
Operating
Default
value
10.00V
100.0%
0.100s
-10.00V
-100.0%
0.00V
0.0%
0.00V
0.0%
10.00V
100.0%
0.100s
0
0.000KHz
0.0%
50.000KHz
