Goodrive350-19 series VFD
Function
Name
code
Spindle
P22.09 scale-division
angle 3
Spindle
P22.10 scale-division
angle 4
Spindle
P22.11 scale-division
angle 5
Spindle
P22.12 scale-division
angle 6
Spindle
P22.13 scale-division
angle 7
P22.14 Spindle drive ratio
Zero-point
P22.15 communication
setup of spindle
Reserved
P22.16
variables
Reserved
P22.17
variables
Rigid tapping
P22.18
selection
Description
Setting range: 0.00–359.99
Setting range: 0.00–359.99
Setting range: 0.00–359.99
Setting range: 0.00–359.99
Setting range: 0.00–359.99
This function code sets the reduction ratio of the
spindle and the mounting shaft of the encoder.
Setting range: 0.000–30.000
P22.15 sets spindle zero-point offset, if the
selected spindle zero point is P22.03, the final
spindle zero point will be the sum of P22.03 and
P22.15.
Setting range: 0–39999
0–65535
0–65535
Ones: Whether to enable
0: Disable
1: Enable
- 328 -
Function parameter list
Default
Modify
value
○
45.00
○
60.00
○
90.00
○
120.00
○
180.00
○
1.000
○
0
○
0
○
0
◎
0x00
