INVT Goodrive350-19 Series Operation Manual page 390

Goodrive350-19 series VFD
Function
Name
code
Loose rope
P93.19
autotuning
Enabling loose
P93.20
rope protection
Loose rope
P93.21
detection method
Upward fixed
P93.22 value of external
loose rope signal
Downward fixed
P93.23 value of external
loose rope signal
Torque setting for
P93.24 upward loose
rope protection
Torque setting for
P93.25 downward loose
rope protection
Loose rope
protection
P93.26
maintenance
frequency
Loose rope
P93.27 protection
maintenance time
Loose rope
P93.28
detection delay
Description
reference point, during downward limit,
P93.18=0.00m)
0: Invalid
1: Autotuning for upward
2: Autotuning for downward
0–2
0: Disable
1: Enable
2: Enable stable lifting protection
0–2
0: Set through torque
1: Set through torque autotuning
2: Set through external signal detection (AI1)
0.0–10.0V
0.0–10.0V
After loose rope protection is enabled, loose rope
detection is performed during hoist startup:
When the hoist runs upward and reaches P93.26,
torque detection is performed after the delay
P93.28. If the detected status is non loose rope
(Torque value > Loose rope torque P93.24 or
P93.25 for downward running), normal ACC/DEC
is performed.
If the detected status is loose rope (Torque value
<= Loose rope torque P93.24), the output
frequency is restricted to P93.26 within P93.27.
If load holding, (Torque value) > (Loose rope
torque P93.24+2%), is detected within P93.27,
normal ACC/DEC is performed from this time.
If the time exceeds P93.27, normal ACC/DEC is
performed from this time.
P93.24 can be set with the reference to the
autotuning result P93.33. Generally, the value of
- 383 -
Function parameter list
Default
Modify
value
◎
0
◎
0
◎
0
○
0.0V
○
0.0V
○
5.0%
○
5.0%
○
15.00Hz
○
2.0s
○
0.5s
