INVT Goodrive350-19 Series Operation Manual page 362

Goodrive350-19 series VFD
Function
Name
code
Jogging brake
P90.36
type
Description
Frequency
reference
0
Output
current %
P90.33
Start/stop
command
Brake
feedback
signal
Brake
action
Brake
exception
status
Enabling brake
status monitoring
P90.32 setting range: 0.00–20.000s
P90.33 setting range: 0.0%–200.0% (100.0%
corresponding to the motor rated current)
P90.34 setting range: 0–1
0: Disable (Report the brake feedback fault FAE
directly)
1: Enable brake status error speed giving (Report
the brake feedback alarm A-FA simultaneously)
P90.35 setting range: 0.00–50.00Hz
0x00–0x11
Ones place: Brake release type selection
0: Same as hoisting-oriented brake release
frequency
1: Same as jogging frequency
Same as the hoisting-oriented brake release frequency
Output
frequency
P90.16/P90.17
Brake status Close Release
Tens place: Brake closing type selection
0: Same as hoisting-oriented brake closing
frequency
- 355 -
Fault
Not open the
brake
P90.32
Brake
feedback
exception
Fault
Same as jogging frequency
Output
frequency
P08.06
Brake status Close Release
Function parameter list
Default
Modify
value
Time
Time
◎
0x00
