INVT Goodrive350-19 Series Operation Manual page 447

Goodrive350-19 series VFD
01
VFD
address
Assume that the following response is returned:
01
VFD
address
The data content returned by the VFD is 0003H, which indicates that the VFD is in the stopped state.
Example 2: View information about the VFD whose address is 03H, including "Type of current fault"
(P07.27) to "Type of last but four fault" (P07.32) of which the parameter addresses are 071BH to
0720H (contiguous 6 parameter addresses starting from 071BH).
The command transmitted to the VFD is as follows:
03
VFD
address
Assume that the following response is returned:
03 03 0C 00 23 00 23 00 23 00 23
VFD Read Number of
address command
bytes
From the returned data, we can see that all the fault types are 0023H, that is, 35 in the decimal form,
which means the maladjustment fault (STo)
10.4.8.2 Write command 06H examples
Example 1: Set the VFD whose address is 03H to be forward running. Refer to the table of other
function parameters, the address of "Communication-based control command" is 2000H, and 0001H
indicates forward running, as shown in the following figure.
Function
Communication-based
control command
03 21 00
Parameter
Read
address
command
03
Read
command
03 07 1B
Read
Start
command
address
Type of Type of
last fault
current fault
Address
2000H 0001H: Forward running
0002H: Reverse running
0003H: Forward jogging
0004H: Reverse jogging
00 01
Data quantity
02 00 03
Number
Data content
of bytes
00 06
6 parameters in total
Type of last Type of last
but one fault but two fault
Data description
- 440 -
Communication protocols
8E 36
CRC
F8 45
CRC
B5 59
CRC
00 23 00 23
Type of last
Type of last
but three fault
but four fault
5F D2
CRC
R/W
R/W
