INVT Goodrive350-19 Series Operation Manual page 47

Goodrive350-19 series VFD
Note: In closed-loop mode, when the encoder is abnormal, set P90.00=1 to switch to the open-loop
vector control mode. The two modes are different in the brake timing sequence logic, and therefore
you need to adjust P01 and P90 parameters accordingly.
5.1.3 Macro parameters (P90.00=1)
Function
code
P00.00 Speed control mode
Command running
P00.01
P00.03 Max. output frequency
Upper limit of running
P00.04
Setting channel of A
P00.06
frequency command
P00.11
P00.12
P00.14 Carrier frequency setting
Starting frequency of direct
P01.01
P01.15
P01.24
P05.00
P05.03 Function of S3 terminal
P05.04 Function of S4 terminal
P05.05 Function of HDIA terminal
P05.06 Function of HDIB terminal
P06.00
P06.02 HDO output selection
P06.03 RO1 output selection
P06.04 RO2 output selection
P11.08
overload/underload alarm
Underload pre-alarm
P11.11
P25.01 Function of S5 terminal
P25.02 Function of S6 terminal
Enabling brake-oriented
P90.04
Name
channel
frequency
ACC time 1
DEC time 1
start
Stop speed
Stop speed delay
HDI input type
HDO output type
VFD or motor
detection level
logic
Setting
1
1
100.00Hz
90.00Hz
15
8.0s
4.0s
1.5kHz
1.00Hz
1.50 Hz
0.4s
0x11
77 Graded reference terminal 1
78 Graded reference terminal 2
79 Graded reference terminal 3
80 Graded reference terminal 4
1
56
49
5
Underload protection is enabled to
0x021
enhance equipment safety
15%
7
75
1 The brake is controlled by the VFD.
- 40 -
Remarks
SVC mode 1
Terminal
Graded multi-step speed
HDIA is digital input
HDIB is digital input
Open collector output
Brake detection reminding
Brake output
VFD fault
Fault reset
Brake feedback signal
Commissioning
