Goodrive350-19 series VFD
S1
S2
COM
PW
+ 24V
Internal power（PNP mode）
4.4.3 Control circuit wiring of I/O extension card 2
Extension terminal
S5
Extension terminal
S6
Extension terminal
S7
Extension terminal
S8
(Externally connected
temperature resistor)
COM
+ 24V
Figure 4.21 PNP mode
Goodrive350-19 series extension card
S5
S6
S7
S8
COM
PW
+24V
PE
PT1+
Temperature input
PT2+
PT-
PE
Figure 4.22 Control circuit wiring of I/O extension card 2
S1
S2
COM
PW
+ 24V
External power（PNP mode）
- 35 -
COM
+ 24V
RO3A
Relay 3 output
RO3C
RO4A
Relay 4 output
RO4C
Installing
