INVT Goodrive350-19 Series Operation Manual page 254

Goodrive350-19 series VFD
Function
Name
code
HDIA high-speed
P05.38 pulse input
function
Lower limit
P05.39
frequency of HDIA
Corresponding
setting of lower
P05.40
limit frequency of
HDIA
Upper limit
P05.41
frequency of HDIA
Corresponding
setting of upper
P05.42
limit frequency of
HDIA
HDIA frequency
P05.43
input filter time
HDIB high-speed
P05.44 pulse input
function selection
Lower limit
P05.45
frequency of HDIB
Corresponding
P05.46
setting of lower
Description
Setting range of P05.35: P05.33–10.00V
Setting range of P05.36: -300.0%–300.0%
Setting range of P05.37: 0.000s–10.000s
0: Set input via frequency
1: Reserved
2: Input via encoder, used in combination with
HDIB
0.000 KHz – P05.41
-300.0%–300.0%
P05.39 –50.000KHz
-100.0%–100.0%
0.000s–10.000s
0: Set input via frequency
1: Reserved
2: Encoder input, it should be used in combination
with HDIA
0.000 KHz – P05.47
-300.0%–300.0%
- 247 -
Function parameter list
Default
Modify
value
◎
0
0.000
○
KHz
○
0.0%
50.000
○
KHz
○
100.0%
○
0.030s
◎
0
0.000
○
KHz
○
0.0%
