Goodrive350-19 series VFD
VFD model
GD350-19-110G-4-B
GD350-19-132G-4
GD350-19-160G-4
GD350-19-185G-4
GD350-19-200G-4
GD350-19-220G-4
GD350-19-250G-4
GD350-19-280G-4
GD350-19-315G-4
GD350-19-355G-4
GD350-19-400G-4
GD350-19-450G-4
GD350-19-500G-4
Note: The accessory specifications described in the preceding table are ideal values. You can select
accessories based on the actual market conditions, but try not to use those with lower values.
VFD model
GD350-19-022G-6
GD350-19-030G-6
GD350-19-037G-6
GD350-19-045G-6
GD350-19-055G-6
GD350-19-075G-6
GD350-19-090G-6
GD350-19-110G-6
GD350-19-132G-6
GD350-19-160G-6
GD350-19-185G-6
GD350-19-200G-6
GD350-19-220G-6
GD350-19-250G-6
GD350-19-280G-6
Fuse (A)
630
720
870
1110
1110
1230
1380
1500
1740
1860
2010
2445
2505
Table D.4 AC 3PH 520V(-15%)–690V(+10%)
Fuse (A)
105
105
114
138
186
270
270
315
420
480
480
630
720
720
870
-514-
Optional peripheral accessories
Breaker Contactor rated current
(A)
400
400
630
630
630
800
800
1000
1200
1280
1380
1630
1720
Breaker Contactor rated current
(A)
63
63
100
100
125
200
200
200
250
315
315
400
400
400
630
(A)
315
380
450
580
580
630
700
780
900
960
1035
1222
1290
(A)
50
50
63
80
95
135
135
170
230
280
280
315
380
380
450
