Goodrive350-19 series VFD
Function
code
Corresponding setting of
P05.42 upper limit frequency of
HDIA frequency input filter
P05.43
HDIB high-speed pulse input
P05.44
Lower limit frequency of
P05.45
Corresponding setting of
P05.46
lower limit frequency of HDIB
Upper limit frequency of
P05.47
Corresponding setting of
P05.48 upper limit frequency of
HDIB frequency input filter
P05.49
P05.50 AI1 input signal type
Note: When you set P90.04=1 and use the analog reference frequency, use terminals to give the
forward and reverse running commands.
6.5.10 Analog output
GD350-19 series VFD carries one analog output terminal (0–10V/0–20mA) and one high-speed pulse
output terminal. Analog output signals can be filtered separately, and the proportional relation can be
Name
HDIA
HDIA
time
function selection
HDIB
HDIB
HDIB
time
Description
-100.0%–100.0%
0.000s–10.000s
0: Set input via frequency
1: Reserved
2: Input via encoder, used in
combination with HDIA
0.000 KHz – P05.47
-100.0%–100.0%
P05.45 –50.000KHz
-100.0%–100.0%
0.000s–10.000s
0–1
0: Voltage type
1: Current type
- 155 -
Operating
Default
value
100.0%
0.030s
0
0.000KHz
0.0%
50.000KHz
100.0%
0.030s
0
