Goodrive350-19 series VFD
Function
code
P03.36 ASR differential gain
High-frequency ACR
P03.37
proportional coefficient
High-frequency ACR
P03.38
integral coefficient
ACR high-frequency
P03.39
switching threshold
P17.32
6.5.4 SVPWM control mode
GD350-19 VFD also carries built-in SVPWM control function. SVPWM mode can be used in cases
where mediocre control precision is enough. In cases where a VFD needs to drive multiple motors, it
Name
Flux linkage
Description
0: Reserved
1: Reserved
Tens place: Reserved
0: Reserved
1: Reserved
Hundreds place: ASR integral separation
enabling
0: Disabled
1: Enabled
Thousands place: Reserved
0: Reserved
1: Reserved
Range: 0x0000–0x1111
0.00–10.00s
In the closed-loop vector control mode
(P00.00=3), when the frequency is lower
than the ACR high-frequency switching
threshold (P03.39), the ACR PI parameters
are P03.09 and P03.10; and when the
frequency is higher
high-frequency switching
(P03.39), the ACR PI parameters are
P03.37 and P03.38.
Setting range of P03.37: 0–20000
Setting range of P03.38: 0–20000
Setting range of P03.39: 0.0–100.0%
(relative to the maximum frequency)
0.0–200.0%
- 120 -
than the ACR
threshold
Operating
Default
value
0.00s
1000
1000
100.0%
0.0%
