Goodrive350-19 series VFD
two RJ45 interfaces are not distinguished from each other and are interchangeably swappable. They
are arranged as follows:
Pin
1
2
3
4
5
6
7
8
The indicators are described as follows:
The PROFINET communication card has 9 indicators, of which LED1 is the power indicator, LED2–5
are the communication status indicators of the communication card, and LED6–9 are the status
indicators of the network port.
LED
LED1
LED2
(Bus status indicator)
LED3
(System fault indicator)
LED4
(Slave ready indicator)
LED5
(Maintenance status
Name
TX+
TX-
RX+
n/c
n/c
RX-
n/c
n/c
Color State
Green
On
Blinking
Red
Off
On
Green
Off
On
Green Blinking
Off
Green
-465-
Description
Transmit Data+
Transmit Data-
Receive Data+
Not connected
Not connected
Receive Data-
Not connected
Not connected
Description
3.3V power indicator
No network connection
The connection to the network cable
between the Profinet controller is OK,
but the communication is not
established.
Communication with the Profinet
controller has been established
Profinet diagnosis exists
No Profinet diagnosis
TPS-1 protocol stack has started
TPS-1 waits for MCU initialization
TPS-1 protocol stack does not start
Manufacturer-specific - depending on
the characteristics of the device
Extension cards
