INVT Goodrive350-19 Series Operation Manual page 253

Goodrive350-19 series VFD
Function
Name
code
of AI1
Corresponding
P05.27 setting of upper
limit of AI1
Input filter time of
P05.28
AI1
Lower limit value
P05.29
of AI2
Corresponding
P05.30 setting of lower
limit of AI2
Intermediate
P05.31
value 1 of AI2
Corresponding
setting of
P05.32
intermediate
value 1 of AI2
Intermediate
P05.33
value 2 of AI2
Corresponding
setting of
P05.34
intermediate
value 2 of AI2
Upper limit value
P05.35
of AI2
Corresponding
P05.36 setting of upper
limit of AI2
Input filter time of
P05.37
AI2
Description
current corresponds to 0–10V voltage.
In different applications, 100% of analog setting
corresponds to different nominal values.
The figure below illustrates several settings.
100%
-10V
AI2
Input filter time: Adjust the sensitivity of analog
input, increase this value properly can enhance
the anti-interference capacity of analog variables;
however, it will also degrade the sensitivity of
analog input.
Note: AI1 can support 0–10V/0–20mA input, when
AI1 selects 0–20mA input; the corresponding
voltage of 20mA is 10V; AI2 supports -10V–+10V
input.
Setting range of P05.24: 0.00V–P05.26
Setting range of P05.25: -300.0%–300.0%
Setting range of P05.26: P05.24–10.00V
Setting range of P05.27: -300.0%–300.0%
Setting range of P05.28: 0.000s–10.000s
Setting range of P05.29: -10.00V–P05.31
Setting range of P05.30: -300.0%–300.0%
Setting range of P05.31: P05.29–P05.33
Setting range of P05.32: -300.0%–300.0%
Setting range of P05.33: P05.31–P05.35
Setting range of P05.34: -300.0%–300.0%
- 246 -
Corresponding setting
AI
0
10V
20mA
AI1
-100%
Function parameter list
Default
Modify
value
○
100.0%
○
0.030s
○
-10.00V
○
-100.0%
○
0.00V
○
0.0%
○
0.00V
○
0.0%
○
10.00V
○
100.0%
○
0.030s
