Goodrive350-19 series VFD
The indicators are described as follows:
Indicator
No.
LED1
Disconnection
LED2
LED3
EC-PG505-24 can work in combination with multiple types of incremental encoders through various
external wiring modes. It is user-friendly, adopting spring terminals.
EC-PG505-24 terminals are described as follows:
Signal
PE
GND
PWR
PGND
A1+
A1-
B1+
B1-
Z1+
Z1-
Z2-
The following figure shows the external wiring of the PG card when it is used in combination with an
open-drain collector encoder. A pull-up resistor is configured in the PG card.
Name
This indicator is on when the extension card is establishing a
connection with the control board; it blinks periodically after
Status the extension card is properly connected to the control board
indicator (the period is 1s, on for 0.5s, and off for the other 0.5s); and it
is off when the extension card is disconnected from the control
board.
This indicator is off when A1 and B1 of the encoder are
indicator disconnected; it is on when the encoder pulses are normal
Power This indicator is on after the control board feeds power to the
indicator PG card.
Port
Protective earth
terminal
Ground
Encoder power
Encoder interface
Function
Terminal function
Connected to the ground to enhance
anti-interference performance.
Ground of the PCB internal power.
Voltage: 24V ± 5%
Max. current: 150 mA
(PGND is the isolation power ground.)
1. Supporting push-pull interfaces of 24V
2. Supporting open collector interfaces of 24V
3. Supporting differential interfaces of 24V
4. Response frequency: 200 kHz
5. Support the encoder cable length of up to 50m
-482-
Extension cards
