Goodrive350-19 series VFD
Function
code
Torque setup mode
P03.11
P03.12 Torque set by keypad
P03.13 Torque reference filter time 0.000–10.000s
Source of upper limit
P03.14 frequency setup of forward
rotation in torque control
Name
1: Set via keypad (P03.12)
2: Set via AI1 (100% corresponds to three
times of rated motor current)
3: Set via AI2 (the same as above)
4: Set via AI3 (the same as above)
5: Set via pulse frequency HDIA (the same
as above)
6: Set via multi-step torque (the same as
above)
7: Set via MODBUS communication (the
same as above)
8: Set via PROFIBUS/CANopen/DeviceNet
selection
communication (the same as above)
9: Set via Ethernet communication (the
same as above)
10: Set via pulse frequency HDIB (the
same as above)
11: Set via EtherCat/Profinet
communication
12: Set via PLC
corresponds to three times of rated motor
current.
-300.0%–300.0% (motor rated current)
0: Keypad (P03.16)
1:
frequency)
2: AI2 (the same as above)
3: AI3 (the same as above)
Description
Note: For the options 2–12, 100%
AI1 (100% corresponds
- 117 -
Operating
Default
value
1
50.0%
0.010s
to max.
0
