Goodrive350-19 series VFD
Function
Name
code
Analog filter time
P22.19
of rigid tapping
Max. frequency of
P22.20
rigid tapping
Corresponding
frequency of
P22.21
analog zero drift
of rigid tapping
Pulse reference
P22.22 speed measuring
method
P22.23 Reserved
Encoder counting
P22.24
clearing setting
7.2.23 P23 Vector control of motor 2
Function
Name
code
Speed loop
P23.00 proportional gain
1
Speed loop
P23.01
integral time 1
Description
Tens: Analog port selection
0: Invalid
1: AI1
2: AI2
3: AI3
0.0ms–1000.0ms
0.00–400.00Hz
0.00–10.00Hz
0–2
0: Measured by the main control board
1: Measured by the PG card
2: Hybrid speed measuring
0–65535
0–65535
Description
P23.00–P23.05 fit for vector control mode only.
Below switch-over frequency 1 (P23.02), the
speed loop PI parameters are P23.00 and P23.01.
Above switch-over frequency 2 (P23.05), the
speed loop PI parameters are P23.03 and P23.04;
- 329 -
Function parameter list
Default
Modify
value
○
1.0ms
○
50.00Hz
○
0.00Hz
○
0
0
○
0
Default
Modify
value
○
20.0
○
0.200s
