10. SI Unit

10.1. Parts and description

EX245-FPS1
EX245-FPS2
Safe input connection
4 x M12, 5-way sockets
LED indicators 2
LED indicators 1
Switch cover
Production label
Mounting hole
PROFINET connection for Port1 (XF1)
Push Pull connector
EX245-FPS1: SCRJ
EX245-FPS2: RJ45
Fig. 10-1 Allocation of parts on the EX245-FPS1/2
- 49 -
PROFINET connection for Port2 (XF2)
Push Pull connector
EX245-FPS1: SCRJ
EX245-FPS2: RJ45
Connector label
Power connection (XD2)
Push Pull connectors (24 Volt)
Power connection (XD1)
Push Pull connectors (24 Volt)
