Table 10-7 Byte 0 Safe power supply for Safety Mode (Module Passivation/xxx) (outputs)
Bit
0
Safe power supply of US2 to the IO modules
1
Safe power supply of US2 to the valve zone 1
2
Safe power supply of US2 to the valve zone 2
3
Safe power supply of US2 to the valve zone 3
4...7
Reserved
Table 10-8 Byte1 Output feedback parameter for zone M for Safety Mode (Module Passivation/xxx)
Bit 2
Bit 1
Bit 0
Value for OFF feedback delay time for Zone M
0
0
0
Reserved
0
0
1
Reserved
0
1
0
Reserved
0
1
1
5 sec
1
0
0
1 sec
1
0
1
500 msec
1
1
0
200 msec
1
1
1
100 msec
Bit 5
Bit 4
Bit 3
Value for ON feedback delay time for Zone M
0
0
0
Reserved
0
0
1
Reserved
0
1
0
Reserved
0
1
1
5 sec
1
0
0
1 sec
1
0
1
500 msec
1
1
0
200 msec
1
1
1
100 msec
Bit 6
Output feedback for Zone M
0
Disable
1
Enable
Bit 7
Reserved
Description
- 55 -
Explanation
0: OFF, 1: ON
0: OFF, 1: ON
0: OFF, 1: ON
0: OFF, 1: ON
Fixed 0
No.EX##-OMY0004
