Error Codes for Diagnostic Messages
Code Additional Information
The least significant four bits
0x021X
display information on the
affected output.
Range of values:
529dez
1: Zone Z1
530dez
2: Zone Z2
531dez
3: Zone Z3
The least significant four bits
0x023X
display information on the
affected output.
Range of values:
560dez
0: M
561dez
1: Zone Z1
562dez
2: Zone Z2
563dez
3: Zone Z3
The least significant four bits
0x025X
display information on the
affected output.
Range of values:
592dez
0: M (High side switch)
593dez
1: Zone Z1
594dez
2: Zone Z2
595dez
3: Zone Z3
600dez
8: M (Low side switch)
The least significant four bits
0x026X
display information on the
affected output.
Range of values:
0: M (High side switch)
608dez
1: Zone Z1 (High side switch)
609dez
2: Zone Z2 (High side switch)
610dez
3: Zone Z3 (High side switch)
611dez
8: M (Low side switch)
616dez
9: Zone Z1, Z2, Z3 (Common low
617dez
side switch)
The least significant four bits
0x028X
display information on the
affected output.
Range of values:
0: M (High side switch)
640dez
8: M (Low side switch)
648dez
9: Zone Z1, Z2, Z3 (Common low
649dez
side switch)
Brief Description
Until error acknowledgement all outputs are also
Error in the internal returned to the safe state via the general shutdown
monitoring of the paths. Possible cause is a hardware or cross-circuit
return read signals. error. The error is displayed on the device by the
The output displayed red illuminated output LEDs. An acknowledgement
cannot be switched off of this diagnostic message, provided there are no
or there is a hardware other relevant error messages present, deletes the
error. message, cancels the red LEDs and restarts the
outputs.
The error is displayed by the red illuminated LED
At the output displayed for the affected output on the device. An
a short-circuit or an acknowledgement of this diagnostic message is
overload was possible. The acknowledgement deletes the
detected. message and enables a restart of the affected
output.
An error was detected during the test by briefly
switching on at the displayed output. A possible
cause could be a short-circuit/cross-circuit. The test
error could, however, indicate a hardware error. As
Hardware test error a result, until error acknowledgement all outputs
detected. Test through are also returned to a safe state via the general
"light switching" on the shutdown paths. The error is displayed on the
displayed output failed. device by the red illuminated output LEDs.
An acknowledgement of this diagnostic message,
provided there are no other relevant error
messages present, deletes the message, cancels
the red LEDs and restarts the outputs.
An error was detected during the test by briefly
switching off at the displayed output. The test error
could however indicate a cross-circuit or a
hardware error. As a result, until error
Hardware test error acknowledgement all outputs are also returned to a
detected. Test through safe state via the general shutdown paths. The
"dark switching" on the error is displayed on the device by the red
displayed output failed. illuminated output LEDs.
An acknowledgement of this diagnostic message,
provided there are no other relevant error
messages present, deletes the message, cancels
the red LEDs and restarts the outputs.
The US2 supply should be checked. The state error
Error in the internal could, however, indicate a hardware error. As a
monitoring of the result, until error acknowledgement all outputs are
return read signals. also returned to a safe state via the general
The state does not shutdown paths. The error is displayed on the
correspond to the device by the red illuminated output LEDs.
expected value. All An acknowledgement of this diagnostic message,
outputs are maintained provided there are no other relevant error
in a safe state. messages present, deletes the message, cancels
the red LEDs and restarts the outputs.
