Table 10-11 Byte4 Safe input parameter for Ch.0 and Ch.4 (input connector 0) for Safety Mode (Module
Bit 1 Bit 0
0 0
0 1
1 0
1 1
Bit 3 Bit 2
0 0
0 1
1 0
1 1
Bit 6 Bit 5 Bit 4
0 0 0
0 0 1
0 1 0
0 1 1
1 0 0
1 0 1
1 1 0
1 1 1
Bit 7
0
1
* When using 1oo1, please set "No limit (Disable)" for Discrepancy time in Ch.n and Ch.n+4.
Table 10-12 Byte5 Safe input parameter for Ch.1 and Ch.5 (input connector 1) for Safety Mode (Module
Bit 1 Bit 0
0 0
0 1
1 0
1 1
Bit 3 Bit 2
0 0
0 1
1 0
1 1
Bit 6 Bit 5 Bit 4
Same as Table 10-11
Bit 7
Same as Table 10-11
Passivation/xxx)
Sensor evaluation for Ch.0 and Ch.4 (input connector 0)
Disable
1 out of 1 evaluation (Input 0, 4) *
1 out of 2 evaluation, 2-channel equivalent
1 out of 2 evaluation, 2-channel non-equivalent
Power source for cross circuit detection and Clock pulse for Ch.0 and Ch.4 (input
connector 0)
Input 0 power source: UT1 with clock pulse
Input 4 power source: UT2 with clock pulse
Input 0 & 4 power source: UT1 with clock pulse
Input 0 & 4 power source: UT2 with clock pulse
Input 0 & 4 power source: each power source without clock pulse
Discrepancy time for Ch.0 and Ch.4 (input connector 0)
Reserved
No limit (Disable)
10 msec
50 msec
100 msec
1 sec
5 sec
Reserved
Input filter time for Ch.0 and Ch.4 (input connector 0)
3 msec
5 msec
Passivation/xxx)
Sensor evaluation for Ch.1 and Ch.5 (input connector 1)
Disable
1 out of 1 evaluation (Input 1, 5)
1 out of 2 evaluation, 2-channel equivalent
1 out of 2 evaluation, 2-channel non-equivalent
Power source for cross circuit detection and Clock pulse for Ch.1 and Ch.5 (input
connector 1)
Input 1 power source: UT1 with clock pulse
Input 5 power source: UT2 with clock pulse
Input 1 & 5 power source: UT1 with clock pulse
Input 1 & 5 power source: UT2 with clock pulse
Input 1 & 5 power source: each power source without clock pulse
Discrepancy time for Ch.1 and Ch.5 (input connector 1)
Input filter time for Ch.1 and Ch.5 (input connector 1)
