Table 10-9 Byte2 Output feedback parameter zone 1 for Safety Mode (Module Passivation/xxx)
Bit 2 Bit 1 Bit 0
Same as Table 10-8
Bit 5 Bit 4 Bit 3
Same as Table 10-8
Bit 6
0
1
Bit 7
Table 10-10 Byte3 Output feedback parameter zone 2 and zone 3 for Safety Mode (Module Passivation/xxx)
Bit 2 Bit 1 Bit 0
Same as Table 10-8
Bit 5 Bit 4 Bit 3
Same as Table 10-8
Bit 6
0
1
Bit 7
0
1
Value for OFF feedback delay time for zone 1
Value for ON feedback delay time for zone 1
Output feedback for Zone 1
Disable
Enable
Reserved
Value for OFF feedback delay time for zone 2 and zone 3
Value for ON feedback delay time for zone 2 and zone 3
Output feedback for Zone 2
Disable
Enable
Output feedback for Zone 3
Disable
Enable
