E1: Planning
Device type/equipment identification
Version: HW/FW
Test engineer 1
Remark
No.
Has the current module user manual been used as the basis for
1
planning?
Are the actuators approved for connection to the module
2
(according to the technical data and parameterization options?)
Has the voltage supply been planned according to the
3 specifications for the protective extra-low voltage in according
with PELV?
Has the power supply of US1 and US2 from a power supply
4
unit been planned?
Is external protection of the module planned (according to the
5 specifications in this user manual for supply voltage US1 and
US2)
Are measures planned to prevent simple manipulation of US1
6
and US2?
7 Are measures planned to prevent connectors being mixed up?
Are requirements for the actuators and cable installation
8 observed according to the SIL/SILCL/Cat./PL to be achieved
and is the corresponding implementation planned?
Are the specifications for the parameterization for each channel
9
specified?
Are test intervals specified for testing the shutdown capability of
10 the actuators, if this is required to achieve a
SIL/SILCL/Cat./PL?
Has it been ensured that any person intentionally starting
11 hazardous movements can only do so with a direct view of the
danger zone?
12 Does the planned use correspond to the intended use?
Are the ambient conditions as well as the maximum mechanical
13
load observed according to the technical data?
Have test intervals been defined and has the maximum
14
duration of use been taken into consideration?
Has the switch-off delay for stop category 1 been observed in
15 the calculation of the total response time fir the
machine/system?
No.
Have specifications for assembly and electrical installation been
16 defined (e.g., EPLAN) and communicated to the relevant
personnel?
Have specifications for startup been defined and communicated
17
to the relevant personnel?
Checklist for planning the use of the module
Requirement (mandatory)
Requirement (optional)
Date
Test engineer 2
Yes
Yes
Date
Date
- 106 -
Remark
Revision:
No Remark
Signature (editor)
Signature (test engineer)
No.EX##-OMY0004
