Error Codes for Parameter Errors
Code Additional Information
0x04CX
The least significant four bits
display information on the
affected output.
Range of values:
0: M
1216dez
1: Zone Z1
1217dez
2: Zone Z2
1218dez
1219dez 3: Zone Z3
0x04DX The least significant four bits
display information on the
affected output.
Range of values:
0: M
1232dez
1: Zone Z1
1233dez
1234dez 2: Zone Z2
3: Zone Z3
1235dez
The least significant four bits
0x030X
display information on the
affected input.
Range of values:
768dez
0: IN0, IN4
769dez
1: IN1, IN5
770dez
2: IN2, IN6
771dez
3: IN3, IN7
0x031X The least significant four bits
display information on the
affected input.
Range of values:
0: IN0
784dez
1: IN1
785dez
786dez 2: IN2
3: IN3
787dez
8: IN4
792dez
793dez 9: IN5
A: IN6
794dez
795dez B: IN7
0x032X
The least significant four bits
display information on the
affected input.
Range of values:
0: IN0
800dez
1: IN1
801dez
802dez 2: IN2
3: IN3
803dez
8: IN4
808dez
809dez 9: IN5
A: IN6
810dez
811dez B: IN7
Brief Description
At least one value of
the parameter data
regarding the Correct value and resend the parameter data to the
feedback monitoring is device.
outside the permitted
range of values.
In the case of an
activated feedback
Correct value and resend the parameter data to the
monitoring the relevant
device.
input(s) must be
occupied.
The parameter sensor
evaluation for the input
Correct value and resend the parameter data to the
pair displayed is
device.
outside the permitted
range.
The filter time setting
for the displayed input Correct value and resend the parameter data to the
is outside the device.
permitted range.
The clock allocation Input parameter regarding the clock allocation is
for the displayed input not permitted.
is outside the Correct value and resend the parameter data to the
permitted range. device.
- 95 -
Solution
