E2: Assembly and Electrical Installation
Device type/equipment identification
Version: HW/FW
Editor
Remark
No.
Was assembly completed according to the specifications
1 (specifications form the planning phase or according to the
user manual)?
2 Are all unused ports fitted with a blanking cap?
Do the cable cross sections and installation correspond to the
3
specifications?
Does the connection technology correspond to the
4 specifications in the technical data and in the relevant user
manual?
No.
5 Is the data width set correctly according to the specifications?
Is the profile/PROFIsafe address set correctly according to the
6
specifications?
E3: Startup and Parameterisation
Device type/equipment identification
Version: HW/FW
Editor
Remark
No.
Was startup completed according to the specifications
1 (specifications from the planning phase or according to the
user manual)?
During startup, is it ensured that any person intentionally
2 starting hazardous movements can only do so with a direct
view of the danger zone?
Are all parameters parameterized for the outputs & inputs and
3
is the F_WD_Time set correctly/
Are the output test pulses parameterized according to the
4
actuator to be connected?
No.
Have safety distances that must be observed been calculated
5
according to the response and delay times implemented/
Checklist for Assembly and Electrical Installation of the module
Requirement (optional)
Requirement (optional)
Checklist for startup and parameterization of the module
Requirement (optional)
Requirement (optional)
Date
Test engineer
Yes
Yes
Date
Date
Date
Test engineer
Yes
Yes
Date
Date
- 107 -
Remark
No Remark
Signature (editor)
Signature (test engineer)
Remark
No Remark
Signature (editor)
Signature (test engineer)
