6. Valve Manifold

The EX245 PROFIsafe product series can be used with various valve manifolds.
For full details refer to the respective product documentation.
Pin No. Valve Zone
1
Common
2
3
4
Zone 1
···
11
12
13
Zone 2
···
20
21
22
Zone 3
···
29
30
···
34
Signal Name
M OUT 1
P OUT 1
SOL 0
···
SOL 7
P OUT 2
SOL 8
···
SOL 15
P OUT 3
SOL 16
···
SOL 23
N. C.
Fig. 6-1 Connector pin assignment for Valve manifold
- 24 -
Pin assignments for this connector
are shown in the table below
Function
Common 0 V when non-error
Power when zone 1 active
Power when zone 1 active and output 0
···
Power when zone 1 active and output 7
Power when zone 2 active
Power when zone 2 active and output 8
···
Power when zone 2 active and output 15
Power when zone 3 active
Power when zone 3 active and output 16
···
Power when zone 3 active and output 23
N. C.
