E4: Validation
Device type/equipment identification
Version: HW/FW
Editor
Remark
No.
Have all the mandatory requirements for the "Planning"
1
checklist been met?
Have all the mandatory requirements for the "Assembly and
2
electrical installation" checklist been met?
Have all the mandatory requirements for the "Startup and
3
parameterization" checklist been met?
Does the parameterization of the safe outputs correspond to
4
the version and the actual connection of the controlled device?
Has the assignment of the actuators to the outputs and the
5 variables of the safe application program been tested(online
status in SafetyProg)?
Has a function test been performed to check all safety
6
functions, in witch the module is involved?
7 Have measures been taken to achieve a specific Cat.?
8 Do all cables correspond to he specifications?
Does the voltage supply correspond to the specifications for
9
the protective extra-low voltage in accordance with PELV?
Have the voltage supply of US1 and US2 in system from a
10
power supply unit been implemented?
Is external protection of the module implemented (according to
11 the specifications in this user manual for supply voltage US1
and US2)?
12 Have measures been taken to prevent simple manipulation?
Are the requirements for the actuators and cable installation
13
observed according to the SIL/SILCL/Cat./PL?
Are the specifications for the parameterization for each
14
channel implemented?
Are test intervals specified for testing the shutdown capability
15 of the actuators, if this is required to achieve a
SIL/SILCL/Cat./PL?
Has it been ensured that any person intentionally starting
16 hazardous movements can only do so with a directly view of
the danger zone?
Checklist for
Requirement (optional)
Date
Test engineer
Yes
Date
Date
- 108 -
Remark
Signature (editor)
Signature (test engineer)
No.EX##-OMY0004
