Trigger Activation
Falling edge
You can set trigger activation as shown below.
Steps:
1. Click Acquisition Control > Trigger Activation.
2. Select Falling Edge or Rising Edge as Trigger Activation.

5.4.5 Set Trigger Debouncer

The external trigger input signal of the camera may have signal bounce that may cause false trigger.
Thus, it is necessary to debounce the external trigger signal, and its sequence diagram is shown
below.
CameraLink Area Scan Camera·User Manual
Parameter
Acquisition Control >
Trigger Activation
Figure 5-16 Set Trigger Activation
Parameter Value
Falling Edge
29
Principle
the trigger signal.
Falling Edge refers to the falling
edge of the trigger signal is
valid, that is camera exposure
and acquisition at the
beginning of the falling edge of
the trigger signal.
