CameraLink Area Scan Camera·User Manual
Table 1-4 Pin Definition (Type IV and Type V)
No.
Signal
1
GND
2
DC_PWR
3
DC_PWR_TEC --
4
DC_PWR_TEC
5
OPT_OUT-
6
OPT_IN-
7
GND_TEC
8
232_RXD
9
232_TXD
10
GND_TEC
11
OPT_OUT+
12
OPT_IN+
I/O Signal
Description
Source
Camera
--
power supply
ground
Camera
--
power supply
TEC power
supply
TEC power
--
supply
Opto-isolated
Line 1 signal
output signal
ground
ground
Line 0 signal
Opto-isolated
ground
intput signal
ground
TEC power
--
supply
ground
--
RS232_RXD
--
RS232_TXD
--
TEC power
supply
ground
Line 1 signal
Opto-isolated
line
output
Line 0 signal
Opto-isolated
line
intput
5
Color
Black
Red
White/Blue
White/Green
Grey
White
Brown
Orange
Blue
Green
Purple
Yellow
