Parameter
Device Command
Timeout
Device Reset
Device Clock Selector
Device Clock Frequency
Device Temperature
Selector
Device Temperature
TEC Enable
TEC Temperature
TEC Fan Speed
The specific parameters vary from device to device and are subject to the actual you got.

9.2 Set Fan

You can set fan as shown below.
Steps:
1. Click Analog Control > Fan Open Threshold.
2. Enter proper value in Fan Open Threshold according to actual demands.
CameraLink Area Scan Camera·User Manual
Read/Write
Read only
Write only
Read and write It selects device clock.
Read and write It is device's pixel clock.
Read and write It selects device temperature, including
Read only
Write only
Write only
Write only
Figure 9-1 Set Fan
Description
It counts the timeout of command.
Click Execute to reset the device.
sensor and mainboard.
It displays the real-time temperature of
the device you selected in Device
Temperature Selector.
It enables TEC. TEC is able to keep the
camera's sensor temperature around
environment temperature to ensure the
normal operation of the camera.
It sets the TEC temperature.
It sets the speed of TEC fan.
65
