The cable color here refers to the color of cable supplied. If cable of other manufacturers is used,
the cable color may differ, and the actual cable you purchased shall prevail.

1.3 Indicator Description

The indicator has different status, and please refer to the following table for the details.
No. Indicator
1 Blue/ red
indicator.
2 Blue/ red
indicator.
3 Blue indicator.
4 Blue indicator.
When the indicator is flashing fast or flashing very slowly, its unlit interval is 0.2 s and 2 s
respectively.
CameraLink Area Scan Camera·User Manual
Table 1-5 Indicator Description
Indicator Status
It is unlit.
It is solid.
It is flashing fast.
It is flashing very slowly.
Description
The camera is powered off, or updating
firmware fails, or loading uboot application
fails.
After powering on, the camera is starting up.
After starting up, the camera shows this
status. The camera is under internal trigger
mode and in transmission status.
External trigger mode, and camera is in
transmission status.
