  • Page 1 SC7000Pro Series Smart Camera Quick Start Guide...
  • Page 2 INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKROBOT HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
  • Page 3 SC7000Pro Series Smart Camera Quick Start Guide THE PERFORMANCE DATA IN THIS PUBLICATION IS BASED ON HIKROBOT'S INTERNAL RESEARCH/EVALUATION. ACTUAL DATA MAY VARY DEPENDING ON SPECIFIC CONFIGURATIONS AND OPERATING CONDITIONS AND HIKROBOT SHALL NOT BEAR THE CONSEQUENCES ARISING THEREFROM. IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER PREVAILS.
  • Page 4 Note important points of the main text. Available Model This manual is applicable to the SC7000Pro Series Smart Camera. Safety Instruction These instructions are intended to ensure that the user can use the device correctly to avoid danger or property loss.
  • Page 5 SC7000Pro Series Smart Camera Quick Start Guide immediately, unplug the power cord, and contact the service center in time. ● To reduce the risk of fire or electric shock, do not expose the device to rain or moisture. ● If the device does not work properly, please contact your dealer or the nearest service center.
  • Page 6 SC7000Pro Series Smart Camera Quick Start Guide components, etc. must share the same ground. ● If the device is powered on and off frequently, it is necessary to strengthen the voltage isolation, and consider adding a DC/DC isolation power supply module between the device and the adapter.

  • Page 7: Table Of Contents

    SC7000Pro Series Smart Camera Quick Start Guide Contents Chapter 1 Overview ..........................1 1.1 Introduction ........................... 1 1.2 Key Feature ..........................1 Chapter 2 Appearance ......................... 2 Chapter 3 12-Pin Interface and Indicator ................... 4 3.1 12-Pin Interface ........................4 3.2 Indicator ..........................
  • Page 8 SC7000Pro Series Smart Camera Quick Start Guide 8.3 Why the image is very dark? ....................21 8.4 Why there is no image in live view? ................... 21 8.5 What can I do if I forget the login password? ..............22...

  • Page 9: Chapter 1 Overview

    Chapter 1 Overview 1.1 Introduction SC7000Pro series smart camera uses the sensor and optical components to acquire images, and adopts built-in deep learning algorithms to realize character and object recognition, object sorting, etc. It can be easily configured and operated via the SCMVS client software, and uses Ethernet to output vision tool results and customized results.

  • Page 10: Chapter 2 Appearance

    SC7000Pro Series Smart Camera Quick Start Guide Chapter 2 Appearance Note Appearance here is for reference only. Refer to the device's specification for detailed dimension information. Figure 2-1 Appearance (Type I) Figure 2-2 Appearance (Type II)
  • Page 11 SC7000Pro Series Smart Camera Quick Start Guide Table 2-1 Component Description Name Description Lens Cap It can be replaced with other lens cap. It is used to fix the device to the installation position. It is recommended Screw Hole to use supplied M4 screws.

  • Page 12: Chapter 3 12-Pin Interface And Indicator

    SC7000Pro Series Smart Camera Quick Start Guide Chapter 3 12-Pin Interface and Indicator 3.1 12-Pin Interface Read the following section to get definitions of 12-pin M12 interface. Figure 3-1 12-Pin M12 Interface Table 3-1 Pin Definitions Signal I/O Signal Source...

  • Page 13: Indicator

    SC7000Pro Series Smart Camera Quick Start Guide Note You should refer to the table above and the label attached to the power and I/O cable to wire the device. 3.2 Indicator The device has five indicators, including PWR, LNK, ACK, U1 and U2 indicators. Read following sections to get the indicator status of the device.

  • Page 14: Chapter 4 Installation

    SC7000Pro Series Smart Camera Quick Start Guide Chapter 4 Installation 4.1 Installation Preparation You need to prepare following accessories before installation. Table 4-1 Accessories Name Quantity Description Some models of the device do not have lens. You need to Lens purchase lens separately.
  • Page 15 SC7000Pro Series Smart Camera Quick Start Guide Figure 4-1 Rear Installation Figure 4-2 Front Installation 3. Use the GigE network cable with RJ45 aviation connector to connect the device to a switch or a network interface card. Figure 4-3 Network Cable Wiring...
  • Page 16 SC7000Pro Series Smart Camera Quick Start Guide 4. Use the power and I/O cable to connect the device to a DC switch power supply. Figure 4-4 Power and I/O Wiring...

  • Page 17: Chapter 5 Device Connection

    SC7000Pro Series Smart Camera Quick Start Guide Chapter 5 Device Connection Device connection to the client software is required for device’s configuration and remote operations. This section introduces how to install the client software, set PC and device network, connect the device to the client software, etc.

  • Page 18: Install Client Software

    SC7000Pro Series Smart Camera Quick Start Guide Note It is recommended to use the static IP address to reduce time for searching the device. 3. Set NIC property. 1) Go to NIC settings page: Control Panel → Hardware and Sound → Device Manager →...

  • Page 19: Set Device Network

    SC7000Pro Series Smart Camera Quick Start Guide 5.3 Set Device Network You can set and operate the device in the client software only when the device is in the same network segment with the PC where the client software is installed.
  • Page 20 SC7000Pro Series Smart Camera Quick Start Guide Steps 1. Click the device in the device list. 2. Enter password. 3. Click to log in. Figure 5-4 Login Interface 4. (Optional) Check Remember me to remember the password if necessary. Note If you forget password, click Forgot Password in the login interface to view the device’s serial No.,...

  • Page 21: Chapter 6 Client Layout And Operation Flow

    SC7000Pro Series Smart Camera Quick Start Guide Chapter 6 Client Layout and Operation Flow 6.1 Main Window Introduction After logging into the client software, you can see the main window as shown below. Figure 6-1 Main Window Note ● The specific interfaces of the client software may differ by its versions.

  • Page 22: Operation Flow

    SC7000Pro Series Smart Camera Quick Start Guide Name Description This area displays images and results under camera mode and image mode Live View Window in real time. Under image mode, you can import images into the device. You can switch languages and cameras, view the user manual and client Other Areas version information here.

  • Page 23: Chapter 7 Electrical Feature And I/O Wiring

    SC7000Pro Series Smart Camera Quick Start Guide Chapter 7 Electrical Feature and I/O Wiring The device has three opto-isolated inputs (Line 0/1/2), three opto-isolated output (Line 3/4/5), and one RS-232 serial port. 7.1 Input Signal The device's Line 0/1/2 is opto-isolated input, and their internal circuit is as follows.

  • Page 24: Output Signal

    SC7000Pro Series Smart Camera Quick Start Guide Table 7-1 Input Electrical Feature Parameter Name Parameter Symbol Value Input Logic Level Low 1.5 VDC Input Logic Level High 2 VDC Input Falling Delay 81.6 μs Input Rising Delay 7 μs 7.2 Output Signal The device's Line 3/4/5 is opto-isolated output, and their internal circuit is as follows.

  • Page 25: Input Signal Wiring

    SC7000Pro Series Smart Camera Quick Start Guide Table 7-2 Output Electrical Feature Parameter Name Parameter Symbol Value Output Logic Level Low 730 mV Output Logic Level High 3.2 VDC Output Falling Delay 6.3 μs Output Rising Delay 68 μs Output Falling Time 3 μs...

  • Page 26: Output Signal Wiring

    SC7000Pro Series Smart Camera Quick Start Guide NPN Device Power ● Device Power Opto-Isolated ● Signal Line Input Device Input Signal Ground ● NPN Power Ground Device Power Ground GND of VCC GND of PWR Figure 7-6 Input Signal Connecting to NPN Device 7.4 Output Signal Wiring...

  • Page 27: Rs-232 Serial Port

    SC7000Pro Series Smart Camera Quick Start Guide 7.5 RS-232 Serial Port The device supports outputting data via the RS-232 serial port. You can go to the communication settings of the client software to set related parameters. 7.5.1 Introduction The 9-pin male connector and 25-pin male connector are commonly used serial ports, as shown below.
  • Page 28 SC7000Pro Series Smart Camera Quick Start Guide Device Power RS-232 Serial Port External Output Device RS-232 Serial Port Input External Device ● Device Power Power Ground Ground Figure 7-11 RS-232 Serial Port Wiring...

  • Page 29: Chapter 8 Faq (Frequently Asked Question)

    SC7000Pro Series Smart Camera Quick Start Guide Chapter 8 FAQ (Frequently Asked Question) 8.1 Why the client software cannot list devices? Reason ● Device is not started up normally. ● Network connection exception occurs. Solution ● Check device power wiring (observe PWR indicator).
  • Page 30 SC7000Pro Series Smart Camera Quick Start Guide Solution Send trigger signal to the device, or disable trigger mode. 8.5 What can I do if I forget the login password? Solution Click Forgot Password in the login interface to view the device serial No., and mail it to the technical support personnel or call them to get the corresponding resetting file.
  • Page 31 UD26521B-A...
