HikRobot CameraLink Area Scan Camera User Manual page 89

PixelFormat
TestPattern
Binning
Decimation
AcquisitionBurstFrame
Count
AcquisitionFrameRate
TriggerMode
TriggerSoftware
CameraLink Area Scan Camera·User Manual
R/W w PixelFormat n
r PixelFormat
R/W
w TestPattern n
r TestPattern
R/W w Binning n
r Binning
R/W w Decimation n
r Decimation
R/W w
AcquisitionBurstFrameCount
n
r
AcquisitionBurstFrameCount
R/W w AcquisitionFrameRate n
r AcquisitionFrameRate
R/W w TriggerMode n
r TriggerMode
W w TriggerSoftware 1
79
0x01080001: Mono8
0x01100003: Mono10
0x01100005: Mono12
0x02180014: RGB 8
0x01080009: BayerRG8
0x0110000d: BayerRG10
0x01100011: BayerRG12
0: off
11: MonoBar
12: HorizontalColorBar
13: Checkboard
14: ObliqueMonoBar
16: GradualMonoBar
bit31-bit16:
BinningVertical
bit15-bit0:
BinningHorizontal
bit31-bit16:
DecimationVertical
bit15-bit1:
DecimationHorizontal
1-1023
1000-1000000000, if
AcquisitionFrameRateEn
able is 1, you need to set
Bit30 as 1.
0: Off
1: On
--
